Aura Car Audio Venom D1000in

Product Overview

AURAVenom-D1000 IN Class D Mono Block Power Amplifier

The Venom Series class D amplifier is Small and Compact Powerhouse Amplifiers. Engineered and developed by Aura sound engineers, It is most Powerful Amplifiers in its category. Each Amplifier designed keeping in mind with the requirements of Car Audio enthusiast and High End Installers Adjusting Gain, HPF/LPF, Bass Boost are some of the features with High End Tiffany RCA terminal Now control your bass with easy Remote control.

Technical Specifications:

• Model No : Venom-D1000 IN
• Amplifier Class : Class D
• Channels : Mono
• RMS Power @ 4 Ohms: 400W X 1
• RMS Power @ 2 Ohms: 600W X 1
• RMS Power @ 1 Ohms: 1000W X 1
• RMS Power @ 4 Ohms(Bridged): N/A
• Working Impedance 1 Ohm Stable
• Input Sensitivity : 6V-0.2V
• Low Pass Filter: 35Hz-250Hz
• High Pass Filter : N/A
• Subsonic Filter: 10-55Hz
• Bass Boost : 0-12dB
• Frequency Response: 10Hz-250Hz
• Signal to Noise Ratio : >85dB
• THD @ 4 Ohms : <0.1%
• Damping Factor : >150
• Working Voltage : 9V-15V
• Fuse Rating : 40AX 2 (80A)
• Dimensions (Inches) : 7.78LX5.28WX2.05H

1 YEAR BRAND WARRANTY

The Venom-D1000 is Class D mono block power amplifier with stable 1 Ohms load, High Speed Mosfet power supply made for Subwoofers in a small compact size. Delivering 1000Wx1@1 Ohms, this mono block can power subwoofer with high power and less distortion. The Small size makes it ideal for user who want to small Size yet powerful amplifiers.

The Venom amplifiers uses High grade PCB parts such Tiffiany RCA unlike the traditional white and Red RCA.

High Grade PCB Circuit Tiffiany RCA

The Venom-D1000 Mono Amplifier has High Level and Low Level inputs with gain and phase controls. The low pass frequencies has a variable frequency selection from 35Hz to 250Hz thus capturing the low frequencies. The Subsonic filter selection can filter frequencies below audible to human ears.

The Amps is protected with two fuses of each 40 Amp and protection mode blinking for any clipping. The two fuses help us on overheating, thermal protection, over load protection and circuit protection.

The Aura Venom Amplifier is ascetically one of the best amplifiers with Aura Logo prominently visible on the hairline finish look heat sink and Red Illumination.

The VENOM amplifiers includes Remote Control , gloves for Installers ,Aura, Venom stickers, Allen key, High input Level cable, Manual and Warranty Card in a beautiful designed Giftbox which denotes the amplifiers design in the background.

Frequently Asked Questions (FAQ)

Q: Can I run this amplifier with a 1-Ohm subwoofer setup?

A: Yes! The Aura Venom-D1000 IN is 1-Ohm stable and delivers its maximum continuous power output of 1000W RMS into a 1-Ohm load.

Q: Can I install this monoblock amp if I still have my car’s factory (OEM) radio?

A: Absolutely. It features both High-Level (speaker wire) and Low-Level (RCA) inputs, allowing you to tap directly into a factory sound system using the provided high-level cable harness.

Q: What is the purpose of the Subsonic filter on the Venom-D1000 IN?

A: The subsonic filter blocks extremely low frequencies (below 10Hz55Hz) that your subwoofer cannot physically reproduce efficiently. This prevents your sub from wasting power or over-excurting on unhearable frequencies.

Q: Does this amplifier come with a bass knob?

A: Yes, the Venom-D1000 IN includes a remote bass controller in the box, allowing you to adjust subwoofer volume directly from the dashboard area.
