Aura Car Audio Venom D5.100in 5 Channel Amplifier

Product Overview

The Venom Series class Damplifier is Small and Compact Powerhouse Amplifiers. Engineered and developed by Aura sound engineers, It is most Powerful Amplifiers in its category. Each Amplifier designed keeping in mind with the requirements of Car Audio enthusiast and High End Installers Adjusting Gain, HPF/LPF, Bass Boost are some of the features with High End Tiffany RCA terminal Now control your bass with easy Remote control.

Technical Specifications:

• Model No : Venom-D5.100 IN
• Amplifier Class : Class D
• Channels : 5 Channel
• RMS Power @ 4 Ohms: 100W X 4 + 320W X 1
• RMS Power @ 2 Ohms: 150WX 4 +500W X 1
• RMS Power @ 4 Ohms(Bridged): 300W X 2
• Working Impedance 2 Ohm Stable(CH1-CH4), 1 Ohm Stable(CH5)
• Input Sensitivity : 6V-0.2V
• Low Pass Filter: 35Hz-250HZ
• High Pass Filter : 15Hz-3KHz
• Subsonic Filter: N/A
• Bass Boost : 0-12dB
• Frequency Response: 10Hz-250Hz(CH5), 15Hz-30KHz(CH1-CH4)
• Signal to Noise Ratio : >85dB
• THD @ 4 Ohms : <0.1%
• Damping Factor : >150
• Working Voltage : 9V-15V
• Fuse Rating : 3x 35A
• Dimensions (Inches) : 12.85 L X 5.87 W X 2.05 H

  The Venom-D5.100 IN is a Class D 5 Channel Power Amplifier with stable 2 Ohms load for CH1-CH4 , Stable 1 Ohms load for CH5, High Speed Mosfet power supply in a small compact size.. Delivering 100WX4@4 Ohms and 500WX1@1 Ohms, this 5 Ch Amplifier is an ideal amplifier for a 2 pairs speakers and subwoofer setup in a cost effective solution. The Small size makes it ideal for user who is looking at 5 Channel set up in space constraint environment.

  The Venom amplifiers uses High grade PCB parts such Tiffiany RCA unlike the traditional white and Red RCA.

  High Grade PCB CircuitTiffiany RCA

  The Venom-D5.80 IN Amplifier has High Level and Low Level inputs with gain & bass boost controls. The low & High pass frequencies has a variable frequency selection from 35Hz to 250Hz and High Frequency of 15Hz-3KHz thus capturing the low & High frequencies.

  The 5 Ch Amp has a protection mode blinking for any clipping. It has built in 80A fuse.

  The Aura Venom Amplifier is ascetically one of the best amplifiers with Aura Logo prominently visible on the hairline finish look heat sink and Red Illumination.

  The VENOM amplifiers includes Remote Control , gloves for Installers ,Aura, Venom stickers, Allen key, High input Level cable, Manual and Warranty Card in a beautiful designed Giftbox which denotes the amplifiers design in the background.

  Frequently Asked Questions (FAQ)

  Q: Why choose a 5-channel amplifier over separate 4-channel and monoblock amps?

  A: A 5-channel amplifier simplifies your installation significantly. It requires only one main power run, one ground wire, and occupies far less physical space while powering both your full-range cabin speakers and your subwoofer.

  Q: Is Channel 5 on the Venom D5.100IN stable at 1 ohm?

  A: Yes! The dedicated subwoofer channel (CH5) is $1ext{-ohm}$ stable, allowing you to run a dual 2-ohm voice coil subwoofer wired in parallel or multiple subwoofers safely at a 1-ohm load.

  Q: Can this amplifier connect to factory OEM head units?

  A: Yes, the Venom D5.100IN features both low-level RCA inputs and high-level speaker inputs, making it compatible with both aftermarket stereos and factory OEM head units.
